How a leading producer of aggregates proactively monitors dust with APT

Discover how a leading mining company reduced silica exposure with real-time monitoring and analysis using APT's innovative dust management solutions.

Understanding MSHA Dust Exposure Metrics

Dust exposure is a major occupational health concern in mining operations, both underground and surface. Prolonged inhalation of airborne particulates—including respirable crystalline silica, coal dust, and metal dust—poses severe health risks, leading to chronic respiratory diseases like silicosis, lung cancer, and COPD.

To protect miners, the Mine Safety and Health Administration (MSHA) has established Permissible Exposure Limits (PELs), which define the maximum allowable concentration of airborne contaminants in mining environments. These exposure limits are measured in milligrams per cubic meter of air (mg/m³) over an 8-hour time-weighted average (TWA) period. MSHA also considers the size and toxicity of dust particles, with finer particulates (such as PM2.5 and PM10) presenting greater health risks.

Understanding these exposure metrics and their impact on mining operations is essential for maintaining compliance and safeguarding worker health. Below, we outline MSHA's specific dust exposure limits, how they are determined, and best practices for dust monitoring and control in mining sites.

What Are MSHA’s Permissible Exposure Limits (PELs) for Dust?

MSHA’s Permissible Exposure Limits (PELs) define the maximum concentration of airborne contaminants that workers can be exposed to during an 8-hour work shift. These limits are measured in milligrams per cubic meter of air (mg/m³) and vary based on dust type.

1. MSHA PEL for Respirable Dust in Coal Mines

  • 15 mg/m³ for total dust (which includes larger, non-respirable particles).
  • Applies to both underground and surface coal mines.

2. MSHA PEL for Respirable Crystalline Silica

  • 50 µg/m³ (0.05 mg/m³) as an 8-hour TWA, aligning with federal recommendations.
  • Critical for operations where sand, stone, and silica-containing materials are processed.

3. MSHA PEL for Metal/Nonmetal Mines

  • Generally, 5 mg/m³ for respirable dust unless specific contaminants have lower limits.
  • Special attention is given to dust from drilling, blasting, and crushing activities.

How MSHA Determines Dust Exposure Limits

MSHA bases its dust exposure limits on the following:

  • Health risks associated with specific dust types (e.g., silica and coal dust are highly hazardous).
  • Particle size, as smaller particles penetrate deeper into the lungs.
  • Exposure scenarios specific to mining, such as enclosed environments and continuous mining operations.
  • Scientific research and federal recommendations from agencies like NIOSH.

Monitoring and Controlling Dust in Mining Sites

1. Real-Time Dust Monitoring

Mining operators are required to conduct continuous dust sampling and utilize real-time monitoring devices to assess exposure.

  • Personal wearable monitors (e.g., MINIMA, Trolex XD1+, Nanozen DustCount 9000) measure real-time dust exposure and provide data within workers’ breathing zones.
  • Fixed industrial air monitoring systems help track dust accumulation in high-risk zones.

2. Engineering Controls

  • Ventilation Systems – Improves airflow to reduce dust concentration.
  • Wet Methods – Using water sprays to suppress airborne dust during cutting, drilling, and grinding.
  • Dust Collection Systems – HEPA filtration systems that capture fine particulates.

3. Personal Protective Equipment (PPE)

  • Respiratory Protection (N95, P100 masks) – Required in high-dust environments.
  • Protective clothing and gear – Reduces skin and eye exposure and contamination risks.

4. Compliance Training & Regulations

  • MSHA-mandated training for miners on dust exposure hazards and mitigation practices.
  • Routine inspections and documentation of exposure assessments.

Ensuring Compliance and Mitigating Risks

Failure to meet MSHA’s dust regulations can lead to fines, legal penalties, and operational shutdowns. Beyond financial implications, failure to control dust exposes miners to severe respiratory illnesses and can tarnish a company’s reputation.

To mitigate these risks, mining companies must take proactive measures by implementing a comprehensive dust control plan that includes:

  • Real-Time Dust Monitoring: Utilizing wearable and stationary monitoring devices to track exposure levels.
  • Engineering Controls: Enhancing ventilation systems, dust collection, and wet suppression techniques.
  • Personal Protective Equipment (PPE): Ensuring workers have proper respiratory protection and protective clothing.
  • Ongoing training and education to keep all personnel informed and compliant.

By prioritizing advanced monitoring technology, engineering controls, and worker training, mining operations can maintain compliance, safeguard worker health, and ensure uninterrupted production. Investing in proactive dust management is not only regulatory compliance—it’s a commitment to long-term operational excellence.

Investing in advanced dust control solutions is not just a compliance measure—it’s a commitment to worker safety. If your workplace needs expert guidance on dust monitoring and control, reach out to us today to ensure compliance with OSHA standards and protect your workforce.

Take a tour of APT's dust management platform

Vulcan Materials Company is the nation’s largest producer of construction aggregates.

Project partner

Brent Leclerc | Environmental Manager

Problems solved

Unjustified community dust complaints & lawsuits

Difficulty complying with opacity regulations and risk of NOVs

Solution

Real-time dust monitoring

Dust maps proving no community impact, preventing fines & lawsuits

Real-time opacity monitoring, high degree of compliance
